Accuracy
Quality checks allow for an accurate part – every time.
Engineering
Our team of engineers works collaboratively to create die tooling solutions for a variety of needs.
Hardware
Our tooling is used in high-tonnage stamping presses as part of our process to achieve the final product.
Equipment at this location
- Uni-Graphics (22 Seats)
- Catia v5 R19 (1 Seat)
- SDRC (1 Seat)
- Rhinoceros Software (1 Seat)
- Work NC (5 Seats)
- Lemoine (9 Seats)
- VisView (Shop Floor Viewing Software) (9 Seats)
- Auto-Form Simulation Software (2 Seats)
- OmniMesh Morphing Software (1 Seat)
- Rapid Form Software (1 Seat)
- 1 – 30/5 Ton Overhead Crane
- 1 – 25 Ton Overhead Crane
- 1 – 20 Ton Overhead Crane
- 2 – 15 Ton Whiting Crane
- 1 – 15 Ton Shaw Box Crane
- 1 – 10 Ton P & H Crane
- 4 – 2 Ton Overhead Cranes
- 1 – 13,000 Lb. Capacity Hi-Lo – Clark Overhead Crane
- 4 – 4,000 Lb Capacity Hi-Lo – Overhead Cranes
- 1 – 1 Ton Clark Hi-Lo – Overhead Crane
- 1 – 5 Ton Kone Crane
- 1 – 5 Ton Robbin & Meyer Crane
1 – Brown & Sharpe Coordinate Measuring Machine with Brown & Sharpe Support Hardware
- 120” X Axis
- 78” Y Axis
- 59” Z Axis
- 2 – Rockwell Hardness Tester
- 1 – Olsen Ductility Tester
- 1 – Ultrasonic Tester
- 1 – Datamyte 3053 Collector With Turbo SPC
1 – Sigma SDV-4224 CNC Double Column Machining Center
- Repeatability Accuracy: +/- 0.003
- Table Size: 86” x 118”
- Table Capacity: 10,000 kgs
- 126” X, 94” Y, 30” Z
- Fanuc 31 I Control
1 – G&L CNC Boring Mill
- 6” Spindle
- 144” X, 96” Y, 48” Z
- G&L 8000 Control
1 – G&L CNC Boring Mill
- 5” Spindle
- 144 X, 96” Y, 48” Z
- Mitsubishi Control
1 – LeBlond Makino CNC Mill
- 67” X, 32” Y, 28” Z
- Creative Control
1 – PARPAS – Moving Column Horizontal Boring Mill
- 236” X, 73” Y, 98” Z
- Mitsubishi Control
1 – OKUMA
- 60.23” X, 25.98” Y, 24.01” Z
- Table Size: 26” x 60”
- Spindle Speed : 6,000 SPM
1 – Taboni Portable Rotary Table
- 40” x 40”
- 0.01 Degrees – CNC Controlled
1 – Mori-Seki
- 40” X, 20” Y, 25” Z
- Mitsubishi Control
- Spindle Speed 6,000 RPM
1 – Toyoda FH630SX-i Horizontal Machining Center
- Travel 41.34” X, 35.43” Y, 41.34” Z
- Fanuc 31i Control
- Spindle Speed 8,000 RPM’s
1 – FPT – Horizontal Spindle CNC Machining Center
- 98” X, 39” Y, 60” Z
- Heidenhain Control
1 – TOS CNC Boring Mill
- 5 1/8” Spindle
- 138” X, 79” Y, 50” Z with CNC Controlled Rotary Table
- Fanuc Control
1 – Mori-Seiki
- NV 5000 2003 VMC
- 31” X, 20” Y, 25” Z
- Hi Pressure Coolant
- Spindle Speed 12,000 RPM’s
1 – 1994 LeBLOND Makino MC 98 with a Fanuc 16MB Control
- (1) 200 Station Automatic Tool Changer
- Coolant through the spindle
- (2) 25” x 25” pallets & is a full 4th Axis
- 36” X, 32" Y & 29.5" Z
- Spindle Speed 10,000 RPM’s
- #50 Taper
